A simple spool valve is arranged in a small widthrectangular body. This has made a compact valve small yet capable of large flow rate.

- Model 414, Spool valve: The main valve is the spool valve, which employs a unique soft seal I-ring for spool packing made of self lubricating material. This has remarkable improved operation reliability.; - Model 416, Ceramic slide valve: This is a lubrication-free slide valve whose main valve adopts super hard ceramic. With its outstanding durability in any type of environment, it is most suitable for both high and low frequency uses.; - 414S・416S（Return）414D・416D（Hold）, 414H・416H（Closed center）414J・416J（Center open to exhaust）414I・416I（Center open to pressure）; - Operation type : （414 type：Pilot-acting Spool valve , 416 type：Pilot-acting Slide valve）;- Gasket-connected type; - Port size：Rc1/8 , Rc1/4 , Rc3/8 , Rc1/2 , Rc3/4 , Rc1（416 type：Rc1/8 , Rc1/4 , Rc3/8 , Rc1/2）

Available are compound manifolds mounting different types of valves（S.D.H.J.I）mixedly.; Optimum wiring connection can be selected according to the site specifications.; Operating confirming Iamp is equipped as standard in every type.

Available are compound manifolds mounting main valves (models 414 and 416)and different types of valves(S.D.H.J.I) mixedly. Optimum wiring connection can be selected according to the site specifications. Piping is also possible to the bottom (A & B ports). Operation indicator lamp is equipped as. Standard in every type.

MVW1F（Normally closed）MVW1RF（Normally open）; Poppet valve system, Direct acting type; Gasket-connected type; Port size：Rc1/8 , Rc1/4 , Rc3/8

MVS2F（Return）MVD2F（Hold）MVPCF（Closed center）MVPOF（Exhaust center）MVPEF（Pressure center）; Spool valve system, Pilot type; Gasket-connected type; Port size：Rc1/4 , Rc3/8 , Rc1/2 , Rc3/4 , Rc1

It is aluminum manifold base which allows solenoid valve units to be simply replaced and maintenance. Also both normal open type and normal close type valves can be integrated together with one manifold unit.

The manifold base is simply integrated with solenoid valves by the bolts. It is easy to replace and maintenance the valves individually without disconnecting the main piping. The difference between SP1 and SP2 type is the position of exhaust ports. The exhaust port is on the side of the body for SP1 and on the bottom of the body for SP2. It can also be connected together with three types of solenoid valves, Single acting, double acting and3-position type.

Suitable for single-acting actuators and diaphragm valves. Two types (NC, NO) are available. The valve incorporates plastic cassette valve, low power consumption solenoid, and DIN connector.

Direct piping type 5-port solenoid valve that is a mainstay of Magster III series. With basic concepts of compact size, large flow, and low power consumption, this high-performance valve has been developed to meet various needs.

Gasket-connection type solenoid valve focusing safety in operation and easy maintenance. Employing sizes complying with ISO and JIS standards, this valve is suitable for multiple applications.

Compact individual exhaust type and collective exhaust type allowing easy maintenance are available. Individual exhaust or collective exhaust type manifold can be selected to meet versatile applications.

Solenoid valve with manifold that allows easy maintenance. Individual exhaust type and collective exhaust type manifolds are available to provide multiple functions and meet many different applications.

With standardized collective exhaust type manifold and sizes complying with ISO and JIS standards, the valve is designed to enhance functionability.

MVW1（Normally closed）MVW1R（Normally open）; Poppet valve system, Direct acting type; Direct piping type; Port size：Rc1/4 , Rc1/8

MVW71,MVW7（Normally closed）MVW71R,MVW7R（Normally open）; Poppet valve system, Pilot-acting type; Direct piping type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1

MVW2（Return）; Spool valve system, Pilot-acting type; Direct piping type; Port size：Rc1/4 , Rc3/8

MVS2（Return）; Spool valve system, Pilot-acting type; Gasket-connected type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1

MVS120C,MVS150C（Return）; Spool valve system, Pilot-acting type; Gasket-connected type; Port size：Rc1 1/4 , Rc1 1/2

MVD2（Hold）; Spool valve system, Pilot-acting type; Gasket-connected type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1

MVD120C,MVD150C（Hold）; Spool valve system, Pilot-acting type; Gasket-connected type; Port size：Rc1 1/4 , Rc1 1/2

MVPC1,MVPC2（Closed center）MVPO1,MVPO2（Center open to exhaust）MVPE1,MVPE2（Center open to pressure）; Spool valve system, Pilot-acting type; Gasket-connected type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1 , Rc1 1/4 , Rc1 1/2

Explosion-proof (d2G4), Drip-proof（Drip-proof protection class : Equivalent to IP54）; Return / Hold; Poppet valve system, Direct acting type; Subplate type Rc1/4

Explosion-proof（d2G4 / ExdⅡBT4）、Drip-proof（Drip-proof protection class : Equivalent to IP54）; Return / Hold; Ceramic slide valve system, Pilot type; Gasket connection type Rc1/4 , 3/8 , 1/2; This valve can be used as a 3-port valve by closing one of OUT ports (plug).

Explosion-proof（d2G4 / ExdⅡBT4）、Drip-proof（Drip-proof protection class : Equivalent to IP54）; Return / Hold; Spool valve system, Pilot type; Direct piping type Rc1/4 , 3/8 , 1/2

Explosion-proof（d2G4 / ExdⅡBT4）、Drip-proof（Drip-proof protection class : Equivalent to IP54）; Return / Hold; Spool valve system, Pilot type; Gasket connection type Rc1/4 , 3/8 , 1/2 , 3/4 , 1

Explosion-proof（d2G4 / ExdⅡBT4）、Drip-proof（Drip-proof protection class : Equivalent to IP54）; 3 positions（Closed center / Pressure center / Exhaust center）; Spool valve system, Pilot type; Gasket connection type Rc1/4 , 3/8 , 1/2 , 3/4 , 1

MVW7F（Normally closed）MVW7FR（Normally open）; Poppet valve system, Pilot type; Direct Piping Type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1 , Rc1 1/4 , Rc1 1/2 , Rc2

MVW7N（Normally closed）; Poppet valve system, Pilot type; Direct Piping Type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1 , Rc1 1/4 , Rc1 1/2 , Rc2

MVW344F（Return）; Poppet valve system, Pilot type; Direct Piping Type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1 , Rc1 1/4 , Rc1 1/2 , Rc2

MVW344N（Hold）; Poppet valve system, Pilot type; Direct Piping Type; Port size：Rc3/8 , Rc1/2 , Rc3/4 , Rc1 , Rc1 1/4 , Rc1 1/2 , Rc2
